Brand Name : hainengzhichuang
Model Number : custom
Place of Origin : Shenzhen, China
MOQ : custom
Price : Negotiable
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Name : 8x1 COB LCD Module
Dot Format : 8x 1
LCD Type : STN-Gray, STN-blue VA
Character Size( mm) : 5.39 x 3.25
Viewing Area(mm) : 62.0 x 18.0
Viewing Direction : ALL
OutlineDimensions (W x H x T) (mm) : 78.0 x 36
Assem. Size(mm) : 53.28*53.28
STN 8x1 Character LCD Module With SGS / ROHS Certificate RYB0801A
1. Typical Applications:
Telephone, Home Automation, Industrial Instruments, Price Tag, Printer, Fax, etc
2. Features:
Transmissive, Transflective and Reflective Mode
Duty Ratio: 1:8~1:34 for one to four line characters
Wide Operation & Storage temperature range
High reliability
Low power consumption
| Item | Description |
| Product Name | 8x1 COB LCD Module |
| Model No. | RYB0801A |
| Dot Format | 8x 1 |
| Outline Dimension(mm) | 84.0 x44.0MAX |
| Assem. Size(mm) | 78.0 x 36 |
| Viewing Area(mm) | 62.0 x 18.0 |
| Character Size( mm) | 5.39 x 3.25 |
| Viewing Angle | 6 O' clock |
| LCD Type | STN-Gray, STN-blue VA |
| Backlight | White LED backlight or No backlight |
| Driver IC | ST7066U |
| Power supply | 5V |
| Interface | Parallel |
| Operating Temp | -20º C~70º C |
| Storage Temp | -30º C~80º C |

FAQ:
1. Q: Order process
 A:PO is placed by clients → PI is issued by Formike → Payment by clients → Lead time is
 confirmed by Formike → Shipping instrction by Clients → Delivery → Cargo tracking →
 Receipt of cargo
 2. Q: Lead time ( after payment is confirmed)
 A: Sample: 1-10 working days
 Volume: 3-60 working days
 3. Q: Payment
 A: T/T , Western union, L/C, Credit card, and Cash
 4. Q: Warranty
 A: 12 months warranty ( Please find more details via our datasheet by item of Limited Warranty)
 5. Q:RMA Process
 A:Claimed by cliens with photos or videos → Sales rep of Formike confirm if have questions
 → Sales rep issue RMA No to clients if confirmed by QA → Return to Formike → Formal
 report after goods received by Formike → Clients confim the analysis report → Proceeding
 as per the Report both agreed
 6. Q:Notes
 A:Please check both appearance and function of products prior to installation.
 Any damage caused by improper use or unprofessional installation is not covered under warranty.
Pre-sales service :
1. Our team design and make solutions based on different requirements from different customers.
2. We provide 24-hours service,and every message you quote inquiry will be replied within 12 hours.
After-sales services:
1. We provide customer service through Skype, phone or email, supply you video or drawing to solve problems.
2. We provide remote control service through internet to achieve real time service, which will short time of solving problems.
3. We have professional engineer customer to keep fastly reply.
|   |
